Engine Type

Single Cylinder, 4 stroke

Cooling System

Air cooled

Transmission System

Chain

Piston Displacement (cc)

149.6ml

Bore  x Stroke

57.4*57.8

Compression Rate

*

Maximum Power (k.w./r/min)

6.2/7500

Maximum Torque (N.m./rpm)

8.2/6500

Starter System

electric start / kick start

Gears

5 speeds with reverse

Overall Length (mm)

2490mm/98in

Overall Width (mm)

1020mm/40.16in

Overall Height (mm)

1150mm/45.28in

Wheel Base (mm)

1975mm/77.76in

Ground Clearance (mm)

100mm/4in

Brake (Front/Rear)

disc / disc

Tire, Front

110/90-16

Tire, Rear

185/60-14

Ignition Type

CDI

Engine Oil Capacity (L)

12L

Max. Speed (km/h)

80km/h / 50ml/h

N.W.(kg)

185kg/408lb

G.W. (kg)

200kg/441lb

Seat Height (mm)

660mm/26in

Battery

12V/10Ah

Frame

iron

Packing size

2300mm*870mm*1100mm/90.55in*34.25in*43.31in
